Battery Passport
EU Battery Regulation (EU) 2023/1542
Language
Portable rechargeable batteries

401220P

Lithium-ion Polymer · Rechargeable pouch cell

HH401220P · HH-DG2025062001 · A0 · 2025-06-20

3.7 V
Nominal voltage
80 mAh
Capacity
0.29 Wh
Nominal energy
≥ 2 g
Weight

Technical specifications

Data as declared in the manufacturer's specification document HH-DG2025062001, version A0, dated 2025-06-20.

Brand name
鸿辉新能源 HONH New Energy
Model no.
401220P HH401220P
Category
Portable rechargeable batteries
Nominal voltage
3.7 V
Charge voltage
4.20 V max. 4.25 V
Capacity
80 mAh
Nominal energy
0.29 Wh
Weight
≥ 2 g Cell weight: 1.8 g
Chemistry
Lithium-ion Polymer
Dimensions (T × W × L)
4.0 × 12.0 × 20.0 mm
Hazardous substances contained (> 0.1%)
<N/A>
Critical raw materials
Pending – to be providedPending
Usable extinguishing agent
Avoid direct water jet. Water spray, foam, carbon dioxide, dry powder.
Manufacturer
HONH New Energy Co., Ltd.
Postal address
No.71 Renmin Road, Qinghutou, Tangxia Town, Dongguan City, Guangdong, P.R. China
Place of manufacture
China
Production date
See battery
Expiry date
See battery
Marking and labeling
CECE marking
Do not dispose of with household waste
Keep out of reach of children
Standards
IEC 62133 · GB/T 18287 · ROHS
EU Declaration of Conformity
Pending – to be providedPending
Specification document
HH-DG2025062001 · Version A0 · 2025-06-20

Cell dimensions

Pouch cell outline, thickness × width × length.

+ − 20.0 mm 12.0 mm T 4.0 mm
4.0 × 12.0 × 20.0 mm — nominal, excluding tabs.

Warning — battery safety

  • Do not short-circuit, crush, puncture, bend or disassemble the cell. A damaged lithium-ion polymer cell can overheat, catch fire or explode.
  • Charge only with a charger designed for 3.7 V lithium-ion polymer cells, at 4.20 V (never above 4.25 V). Do not charge unattended or near flammable materials.
  • Keep away from heat, direct sunlight and water. Do not expose to temperatures above 60 °C.
  • If the cell swells, leaks, smells unusual or becomes hot, stop using it immediately and isolate it in a fireproof container away from combustible material.
  • In case of fire: do not use a direct water jet. Use water spray, foam, carbon dioxide (CO₂) or dry powder extinguishers.
  • Keep out of reach of children. If swallowed, seek medical attention immediately.

Information on Prevention and Management of Waste Batteries

This battery is a rechargeable lithium-ion polymer battery. The information below applies to portable rechargeable batteries under Regulation (EU) 2023/1542.

(a) Role of end-users in waste prevention

Rechargeable batteries prevent waste when they are used for their full service life. Charge this lithium-ion polymer battery only with a charger designed for it, avoid deep discharge and long storage in a fully charged or fully discharged state, and protect it from heat and mechanical damage. Prefer rechargeable batteries over single-use (primary) batteries, and repair a device or replace its battery where possible instead of discarding the whole device.

(b) Role of end-users in separate collection (Article 64)

End-users must dispose of waste batteries separately from other waste, including mixed municipal waste. Waste portable batteries may be returned free of charge to designated collection points, without any obligation to purchase a new battery. Separate collection ensures that valuable materials contained in the battery, such as lithium, cobalt and copper, can be recovered and recycled and that hazardous substances are treated safely.

(c) Separate collection, take-back and collection points, preparation for reuse, repurposing and treatment

Waste portable batteries are collected through municipal collection points, retailer take-back schemes and producer compliance schemes. Retailers that sell portable batteries take back waste portable batteries free of charge. Collected batteries are sent to permitted treatment facilities, where they are sorted and prepared for recycling; where a battery is still suitable, it may be prepared for reuse or repurposing for another application. Built-in batteries should be removed from waste electrical and electronic equipment before the equipment is treated, where this can be done safely.

(d) Safety instructions for handling waste batteries

Tape over the terminals of a waste battery, or keep it in its original packaging, to prevent short circuits. Store waste batteries dry, at room temperature, out of the reach of children and away from flammable materials. Do not dismantle, crush, puncture or burn a waste battery. Damaged, swollen or leaking batteries must be handled with care, placed in a non-flammable container and taken to a collection point as soon as possible.

(e) Meaning of labels and symbols (Article 13)

Crossed-out wheeled bin symbol: The battery must not be disposed of with unsorted municipal (household) waste. It must be collected separately and handed in at a designated collection point.

CE marking: The CE marking indicates that the battery meets the applicable requirements of EU harmonisation legislation, including Regulation (EU) 2023/1542 on batteries and waste batteries, and that the manufacturer has completed the applicable conformity assessment procedure.

(f) Impact of substances on the environment and human health

This battery contains substances which, if released, can harm the environment and human health. Lithium-ion polymer cells contain lithium salts, flammable organic electrolytes and metals such as cobalt, nickel and copper. If waste batteries are landfilled or disposed of with household waste, these substances can contaminate soil and water, and damaged cells can ignite waste during collection and treatment. Disposing of batteries separately and recycling them prevents this pollution and returns critical raw materials to the production cycle.

Certifications & Test Reports

Reports issued by Guangzhou CPUP Certification Technology Service Co., Ltd. (CNAS L11167).

UN38.3 Test Report
DGHH20251222UN01Standard: ST/SG/AC.10/11/Rev.8/Section 38.3 · Date: 2026-01-14
UN38.3 Test Summary
DGHH20251222TS01
MSDS
DGHH20251222MSDS01Material Safety Data Sheet
1.2 m Drop Test
DGHH20251222D01Pass
Stacking Test
DGHH20251222DM01Pass
Transport Classification
DGHH20251222JDS01Non-restricted Goods (By Sea) / 非限制性物品
T1 · Altitude SimulationPass
T2 · Thermal TestPass
T3 · VibrationPass
T4 · ShockPass
T5 · External Short CircuitPass
T6 · Impact / CrushPass
T7 · OverchargePass
T8 · Forced DischargePass

Test Laboratory: Guangzhou CPUP Certification Technology Service Co., Ltd.广州三帕认证技术服务有限公司 · CNAS L11167 · ilac-MRA

Conformity

This cell is manufactured to IEC 62133 (safety of secondary lithium cells), GB/T 18287 and the RoHS Directive. The EU Declaration of Conformity for this model is pending and will be published on this page once issued by the manufacturer.

Manufacturer: HONH New Energy Co., Ltd., No.71 Renmin Road, Qinghutou, Tangxia Town, Dongguan City, Guangdong, P.R. China

Related documents

Original supplier documents for this model. Tap a document to read it here.
